Additional Info

Mileage

State North Carolina
Mileage 16.77
Cities Raleigh
Junctions Interstate 40
Source: December 31, 2015 Interstate Route Log and Finders List
The Cliff Benson Beltline carried an assortment of U.S. routes and NC 50 prior to being renumbered as I-440 - 1979-80 North Carolina Official Highway Map
The initial potion of the Cliff Benson Beltline opened in 1960 as an extension of the U.S. 1 freeway from Chatham and southwest Wake Counties to end at Hillsborough Street. The route was extended another eight miles to Capitol Boulevard in 1963.
The 1993 Gousha North Carolina Map was updated to show the new Interstate designation for the Cliff Benson Beltline.
The I-40/440 concurrency was one of 2-digit Interstates overlapped with a branch route. Other entries include I-95/495 around Washington, DC, I-87/287 across the Hudson River in New York, I-94/694 in the Twin Cities, MN and I-80/580 at Berkeley, CA.

Share

Interstate 440 North Carolina

Routing

Known as the Cliff Benson Beltline, Interstate 440 forms the northern two thirds of the 25.2-mile long Raleigh beltway. The 1960s-built freeway winds northeast from I-40 near Lake Jackson to North Carolina State University and U.S. 70 by Crabtree Valley Mall. U.S. 1 accompanies the route east to Exit 11, as I-440 turns back south. The freeway meets Interstate 495 west of Knightdale, where U.S. 64 combines with the beltline south back to I-40.

History

AASHTO approved the numbering of Interstate 40 from an application by the state of North Carolina on June 9, 1991. Interstate 440 replaced Business Loop I-40 along the Cliff Benson Beltline, which was officially decommissioned by AASHTO at the same time.

When Interstate 440 was first signed, it used cardinal directions based upon the direction of travel. So along the portion through the east side of Raleigh, I-440 used north/south banners, while the stretch to the north used east/west signage.1 The signing of I-440 was later changed to use an inner and outer orientation, similar to those found on the I-277 inner belt freeway around Downtown Charlotte and the I-485 beltway around Mecklenburg County.

One of the former inner/outer trailblazers posted along Interstate 440. These were mostly removed by 2009 with I-440 resigned as an east-west route. Photo taken 07/12/05.

Prior to the designation of Interstate 440 along the Cliff Benson Beltline, U.S. 1, U.S. 64, U.S. 70 and North Carolina 50 utilized portions of the freeway between Cary and the temporary east end at Poole Road. U.S. 401 was added to the route when the Tom Bradshaw Freeway (I-40) portion of the beltway was completed in 1984 as U.S. 64 shifted to the new I-40. Motorist confusion led NCDOT to restore portions of the routes back through the city center in 1991, including U.S. 70, U.S. 401 and NC 50.1

Plans announced in August of 2003 removed the I-440 designation from the concurrency with I-40 along the southern third of the Raleigh belt line while restoring cardinal (east-west) direction banners along the remainder of the route. The renumbering was reinforced by local references to the I-440 segment as the "Beltline" and the I-40/440 portion as simply "I-40".2 According to Brian LeBlanc's Wake County Roads, sign changes were made by 2009.

Highway Guides

Western Terminus - Interstate 40 - southwest Raleigh, North Carolina
Historical Perspective from Interstates 40 & 440 west
Interstates 40 & 440 west passed under Avent Ferry Road on the one mile approach to Exit 293 with U.S. 1. A lane drop defaulted motorists onto the Cliff Benson Beltline east. Photo taken by Chris Patriarca (06/13/03).
Interstate 40 continued with two westbound through lanes along the east side of Cary. U.S. 64 splits with the Tom Bradshaw Freeway to accompany the U.S. 1 freeway southwest to Apex. Photo taken by Chris Patriarca (06/13/03).
A collector distributor roadway (Exit 293) takes motorists to I-440 east & U.S. 1 north back to Raleigh and Wake Forest. This interchange would have doubled as the northern terminus of Interstate 140 had AASHTD approved the designation for the U.S. 1 freeway between Raleigh and Sanford. Photo taken by Chris Patriarca (06/13/03).
A view of the Exit 293B departure of Interstate 440 inner & U.S. 1 north from the Interstate 40 westbound mainline. The two routes overlap with one another until U.S. 1 departs the beltline via Exit 11. Photo taken by Chris Patriarca (06/13/03).
Perspective from Interstate 440 west & U.S. 1 south
This diagrammatic sign shows ramp connections from Interstate 440 and U.S. 1 south to I-40 (Tom Bradshaw Freeway). A full cloverleaf interchange (Exits 1B/A) joins the two freeways. Photo taken 07/12/05.
Historical Perspective from Interstate 440 west & U.S. 1 south
This guide sign was replaced by 2007. It referenced the U.S. 64 relocation from the Beltline back to I-40. The substandard nature of I-440 remains in place today with U.S. 1 transitioning onto its own freeway along side U.S. 64 toward Sanford and Pinehurst in one mile. Photo taken 07/12/05.
Continuing south from the parclo interchange (Exit 1C) with Jones Franklin Road, I-440 west & U.S. 1 south expanded to three lanes for the upcoming c/d roadway (Exit 1) with Interstate 40 and U.S. 64 east. Photo taken 07/12/05.
A trailblazer for Interstate 440 / Outer Beltline was posted prior to the c/d roadway for Interstate 40. Photo taken 07/12/05.
Interstate 440 south and U.S. 1 south split at this point. The left two lanes follow U.S. 1 south and U.S. 64 west toward Apex, Sanford and Asheboro. The I-440 mainline utilized a loop ramp to join I-40 east across the south side of Raleigh. Photo taken 07/12/05.
Looking from the U.S. 1-64 southwest main lanes, these signs were posted above the off-ramp (Exit 1B) to I-40 west for Raleigh-Durham International Airport (RDU) and Durham. Photo taken 07/12/05.
The inner loop of I-440 merged onto I-40 & U.S. 64 east via Exit 1A. Referencing the crossroads with Interstate 95, Benson is the control city for Interstate 40 east. Photo taken 07/12/05.
Perspective from Interstate 40 east
Exit 293A connects Interstate 40 east with U.S. 1 south and U.S. 64 west to Apex, Sanford and Pittsboro. A loop ramp (Exit 293B) follows onto Interstate 440 east & U.S. 1 north. Wake Forest is the control city for the continuation of U.S. 1 beyond the Beltline. Photo taken 05/30/07.
Historical Perspective from Interstate 40 east
Wade Avenue provides a direct route from Interstate 40 east to Interstate 440 & U.S. 1 (Cliff Benson Beltline) from Exit 289. I-40 otherwise meets the Beltline directly at Exit 293.
This ground level guide, the first for the west junction with I-440, was replaced after 2009 when the freeway was expanded to six overall lanes. Photo taken 05/30/07.
Approaching the collector distributor roadway (Exit 293) with Interstate 440 and U.S. 1-64 on I-40 east. Inner and outer direction banners were used along I-440 until 2007. Photo taken by Chris Curley (10/00).
Greenouts applied to the Exit 293 departure by 2007 acknowledged the removal of I-440 from the overlap with I-40 and the relocation of U.S. 64 to run east with I-40 to I-440 and the Knightdale Bypass (I-495).
This sign bridge was replaced by 2011 during widening of Interstate 440. The c/d roadway now departs further west from the Buck Jones Road overpass. Photo taken 05/30/07.
Just beyond the gore point from I-40 east, an Interstate 440 inner beltline trailblazer was posted along side the freeway. Photo taken 05/30/07.
Exit 293B looped away from the c/d roadway of I-40 east to I-440 inner (east) & U.S. 1 north. U.S. 64 was still referenced as well. Vidcap taken 02/14/01.
Eastern Terminus - Interstate 40 - southeast Raleigh, North Carolina
Historical Perspective from Interstate 40 west
One mile south of the three-wye interchange (Exit 301) with Interstate 440 east and U.S. 64 on I-40 west. U.S. 64 joins the city of Raleigh with Interstate 95, Rocky Mount and the Outer Banks of North Carolina. The portion leading east from I-440 to I-540 doubles as Interstate 495. Photo taken 05/30/07.
A lane drop occurs in one half mile at Exit 301 as I-40 turns west with two lanes to merge with U.S. 64 across the south side of Raleigh. Downtown Durham is 30 miles to the northwest of this junction. Photo taken 05/30/07.
A diagrammatic sign outlined the Interstate 40 entrance onto the Raleigh belt line. The sign is still in place, but without the I-440 trailblazers. Photo taken 05/30/07.
Interstate 440 west combines with U.S. 64 east through to Interstate 495. I-440 turns northwest from there to combine with U.S. 1 to the south of Wake Forest.
These signs were changed to remove I-440 inner for I-40 west and change I-440 outer to west. Photo taken 05/30/07.
Historical Perspective from Interstate 40 east
Posted within Rock Quarry Road interchange, this diagrammatic sign preceded the Interstate 440 split with I-40 east by one mile. For the most part, no control cities were used for I-440 at the east junction. Vidcap taken 02/14/01.
Two lanes departed from the left in one half mile for I-440 outer (west) to U.S. 64 at Exit 301. Interstate 40 sees two east control cities: Benson at the junction with Interstate 95 (Exit 328) and the terminus at Wilmington, 119 miles to the southeast. Vidcap taken 02/14/01.
Interstate 40 turned south from the split with I-440 (Cliff Benson Beltline) toward Canton and Benson. Rocky Mount is used for I-440 west for the continuation of U.S. 64 east from Knightdale. Vidcap taken 02/14/01.

Sources:

  1. The Baffling Beltline - A Photo Essay of the Raleigh Beltline's Colorful Past (Adam Prince)
  2. Rhodes, S.D. "Raleigh Beltline to change signage yet again..." Online posting, Yahoo Groups - Southeast Roads and Transport, Aug. 30, 2002.

Page Updated February 10, 2016.
